JL10 Series IC current relay

Current setting range
a) A:0.5-9.99A A:0.5-9.99A
Power consumption
a)AC circuit power consumption
b)DC circuit power consumption
Actuation Time
The action time of 1 times setting value is not more than 40 Ms;2 times the action time of setting value is not more than 35 Ms.
Return time: no greater than 27ms
Return coefficient: 0.85-0.96

Download

Product overview
Product parameter

Use

JL10 series IC current relay is static type AC current relay. Used in relay protection devices for generators, transformers and transmission lines, as a starting element for AC return load or short circuit in power systems, giving alarm signals or removing faults.

This series of products is designed to replace the DL series relay upgrade products. The product has the advantages of high precision, low power consumption, fast action time, high return coefficient, convenient setting, wide tuning range and no jitter when used as low voltage.

Main technical parameters

1. Current setting range
a) A:0.5-9.99A A:0.5-9.99A

2. Power consumption
a)AC circuit power consumption
b)DC circuit power consumption

3. Actuation Time
The action time of 1 times setting value is not more than 40 Ms;2 times the action time of setting value is not more than 35 Ms.

4. Return time: no greater than 27ms

5. Return coefficient: 0.85-0.96

Internal wiring diagram

JL10 Series IC current relay 6
